Tungsten Carbide Core Pins

Tungsten carbide core pins, high hardness, flexural strength, wear-resistant and difficult to collapse missing, not easily broken, suitable for high wear resistance, reduced diameter, a single small amount of deformation of the mold.

Common die diameter, core rod size schedule (Note: the mold height adjustment, unit: mm)

Outer diameter specifications	Core rod size					Outer diameter specifications	Core rod size
Φ5.5	1.0~3.0					Φ25 Φ30 Φ35 Φ40	1.2~9.9 (Each interval of 0.1mm a core rod size)
Φ8	1.0~5.0						10	10.3	10.6	10.9	11
Φ9	1.0~6.0						11.2	11.5	11.7	12	12.2
Φ10	1.0~6.0						12.5	12.8	13	13.3	13.5
Φ10-1	1.0~7.0						13.7	14	14.3	14.5	14.8
Φ12	1.0~8.0						15	15.2	15.5	15.8	16
Φ12-1	1.0~9.0						16.3	16.6	16.8	17	17.2
Φ13	1.0~8.0						17.4	17.7	18	18.2	18.5
Φ14	1.2~8.0						18.8	19	19.2	19.5	19.7
Φ15	1.0~10.0						20	20.2	20.4	20.7	21
Φ15-1	1.0~10.0						21.3	21.5	21.8	22	22.3
Φ16	1.0~10.0						22.5	22.7
Φ18	1.0~10.0
Φ20	1.0~10.0
Φ22	1.0~10.0
Φ45 Φ50 Φ55	1.2~9.9 (Each interval of 0.1mm a core rod size)					Φ60 Φ65 Φ70 Φ80	1.2~9.9 (Each interval of 0.1mm a core rod size)
	10	10.3	10.6	10.9	11		10	10.3	10.6	10.9	11
	11.2	11.5	11.7	12	12.2		11.2	11.5	11.7	12	12.2
	12.5	12.8	13	13.3	13.5		12.5	12.8	13	13.3	13.5
	13.7	14	14.3	14.5	14.8		13.7	14	14.3	14.5	14.8
	15	15.2	15.5	15.8	16		15	15.2	15.5	15.8	16
	16.3	16.6	16.8	17	17.2		16.3	16.6	16.8	17	17.2
	17.4	17.7	18	18.2	18.5		17.4	17.7	18	18.2	18.5
	18.8	19	19.2	19.5	19.7		18.8	19	19.2	19.5	19.7
	20	20.2	20.4	20.7	21		20	20.2	20.4	20.7	21
	21.3	21.5	21.8	22	22.3		21.3	21.5	21.8	22	22.3
	22.5	22.7	23	23.2	23.4		22.5	22.7	23	23.2	23.4
	23.7	24	24.2	24.4	24.7		23.7	24	24.2	24.4	24.7
	25	25.3	30	34.8			25	25.3	30	34.8	39.5
Φ90	39.5	50				Φ100	50	64
Φ110	39.5	50	64	79.5		Φ150	39.5	50	64	79.5	100
Φ170	39.5	50	64	79.5	124	Φ180	39.5	50	64	79.5	124
